Features
- Structure of Automatic Mold-Open.
Patent - Automatic Double-Sided Operative Molding Machine for Rubber.
Patent - Design of two hydraulic cylinders in same direction operation, improved safety and easy for maintenance.
Patent - Each station has its individual cylinder, and changing molds wouldn't impact the production efficiency.
- Large heating plate W: 500 × D: 500 mm available for producing any size of shoe outsoles.
- Daylight Height : 230 mm available for extra-thick mold.
- 6 stations 12 units；two-side operation without waiting time delayed.
- Automatic middle-mold plate flipping device and fully automatic mold slide open system.
- Available for 2-plate, 3-plate, 4-plate mold.
- Customized heating systems: electro thermal, steam-thermal and heat transfer oil thermal.
Specification
| Model | CT-720 |
|---|---|
| Function | Each daylight operated independently and full automatic mold operation. |
| Stations | 6 stations；12 units |
| Clamping Force | 125 tons |
| Cylinder Diameter | Ø300 mm |
| Mold Opening Force | 150 kg |
| Heating Plate Dimension | 500 × 500 mm |
| Daylight Height | 230 mm |
| Hydraulic Motor | 15 HP × 2 ; 5 HP × 2 |
| System Control | PLC and HMI |
| Machine Dimension | 8100 ( W ) × 2400 ( D ) × 3440 ( H ) mm |
| Safety light curtain | 1 set for each daylight |
